20km Fiber Optic Cable
20km Fiber Optic Cable - Image 2
20km Fiber Optic Cable - Image 3

$595.00

Fiber Optic Built-in Sky Module FPV Drone Reel Ultra0.27mm ABS Black 20km

All shipping to final assembly location in Ukraine included in purchase price

  • Check Mark Workshop delivery notification
  • Check Mark Secure Payments
GUARANTEED SAFE CHECKOUT
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
SKU: 15km-fiber-optic-cable Categories: , ,

Description

20KM Fiber Optic Reel
Product model:DPSM-0.27-20KM
Fiber core length:20010M
Product name:UAV Towing Fiber Optic Reel
Fiber type:G657A2
Jacket material /
Unit weight:65g/km
Cable outer diameter:0.27mm±0.1
Operating temperature:（-40~+85） ℃
Tight buffer color :Natural (Transparent)
Fiber interface :Default FC/UPC
Optical fiber attenuation
@1310nm
≤0.35dB/km
Overall loss≤7.2dB (20KM with connector)
@1550nm
≤0.25dB/km
Overall loss≤5.2dB (20KM with connector)
Product dimensions& weight
Material:ABS black
Dimensions:φ14* H36 cm
Loaded reel net weight:1680g
Packaging dimensions& weight
Carton type/Length * width * height/Weight (Excluding module)
Small inner carton /42.0*17.0*18.5 cm /2080g
Large outer carton (6 units / carton) /57.0*45.0*40.0 cm /14200g
